WIRELESS | |
---|---|
Padrões | Wi-Fi 5 IEEE 802.11ac/n/a 5 GHz IEEE 802.11n/b/g 2.4 GHz |
Velocidade de WiFi | AC1350 5 GHz: 867 Mbps (802.11ac) 2.4 GHz: 450 Mbps (802.11n) |
Alcance do sinal WiFi | 3 Bedroom Houses 5× Fixed Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas Beamforming Concentrates wireless signal strength towards clients to expand WiFi range |
Capacidade WiFi | Medium Dual-Band Allocate devices to different bands for optimal performance MU-MIMO Simultaneously communicates with multiple MU-MIMO clients |
Modos de Operação | Router Mode Access Point Mode |
CARACTERÍSTICAS DE HARDWARE | |
---|---|
Interface | 1 Porta WAN 10/100 Mbps 4 Portas LAN 10/100 Mbps |
Botões | Botão Liga / Desliga Botão de Reset/WPS Botão Liga / Desliga do Wi-Fi |
Fonte de Alimentação Externa | 12VDC/1A |
Dimensões (L X C X A) | 9.1 × 5.7 × 1.5 pol. (230 × 144 × 37 mm) |
Antena | 3 x Antenas de 2.4 GHz 2 x Antenas de 5GHz |
HARDWARE | |
---|---|
Processador | Qualcomm CPU |
Portas Ethernet | 1× 10/100 Mbps WAN Port 4× 10/100 Mbps LAN Ports |
Botões | Wi-Fi On/Off Button Power On/Off Button WPS/Reset Button |
Alimentação | 12 V ⎓ 1 A |
CARACTERÍSTICAS WIRELESS | |
---|---|
Padrões Wireless | IEEE 802.11ac/n/a 5GHz IEEE 802.11b/g/n 2.4GHz |
Velocidades Wireless | 450Mbps(2.4GHz) 867Mbps(5GHz) |
Frequência | 2.4-2.5GHz 5.15-5.25GHz |
Potência de Transmissão | CE: <=20dBm (2.4G) <=23dBm (5G) |
Modos Wireless | Roteador Wireless WDS (Four Address) WDS (AP + APC) |
Segurança Wireless | WEP WPA\WPA2 WPA-PSK\WPA2-PSK |
CARACTERÍSTICAS DE SOFTWARE | |
---|---|
QoS | WMM, Bandwidth Control |
Tipo de WAN | Dynamic IP/Static IP/PPPoE/ BigPond/ /L2TP(Dual Access) /PPTP(Dual Access) |
Gerenciamento | Controle de acesso Gerenciamento local Gerenciamento remoto |
DHCP | Server, Client, DHCP Client List, Address Reservation |
VPN Pass-Through | PPTP L2TP IPSec |
Controle de Acesso | Parental Control Local Management Control Host List Access Schedule Rule Management |
Protocolos | IPv4 IPv6 |
Rede de Visitantes | 1× Rede para Convidados 2.4 GHz 1× Rede para Convidados 5 GHz |
SEGURANÇA | |
---|---|
Criptografia WiFi | WEP WPA WPA2 WPA/WPA2-Enterprise (802.1x) |
Segurança de Rede | SPI Firewall Access Control IP & MAC Binding Application Layer Gateway |
Rede para Visitantes | 1× 5 GHz Guest Network 1× 2.4 GHz Guest Network |
VPN Server | OpenVPN PPTP |
SOFTWARE | |
---|---|
Protocolos | IPv4 IPv6 |
Controle dos Pais | URL Filtering Time Controls |
Tipos de WAN | Dynamic IP Static IP PPPoE PPTP L2TP |
Qualidade de Serviço (QoS) | QoS by Device |
Cloud Service | OTA Firmware Upgrade TP-Link ID DDNS |
NAT Forwarding | Port Forwarding Port Triggering DMZ UPnP |
IPTV | IGMP Proxy IGMP Snooping Bridge Tag VLAN |
DHCP | Address Reservation DHCP Client List Server |
DDNS | TP-Link NO-IP DynDNS |
Gerenciamento | Tether App Webpage Check Web Emulator> |
DIMENSÕES | |
---|---|
Dimensões (W×D×H) | 9.1 × 5.7 × 1.5 in (230 × 144 × 37 mm) |
Conteúdo do Pacote | Wi-Fi Router Archer C60 Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
OUTROS | |
---|---|
Requisitos de Sistema | Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) |
Certificações | FCC, CE, RoHS |
Ambiente | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
OUTROS | |
---|---|
Certificação | CE, RoHS |
Conteúdo do Pacote | Roteador Wi-Fi Dual Band Archer C60 AC1350 Fonte de Energia Cabo Ethernet RJ45 Guia de Instalação Rápido |
Ambiente | Temperatura de operação: 0 ℃ ~ 40 ℃ (32 ℉ ~ 104 ℉) Temperatura de armazenamento: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Umidade de operação: 10% ~ 90% sem condensação Umidade de armazenamento: 5% ~ 90% sem condensação |
Sistema de Operação | Microsoft Windows XP/Vista/7/8/8.1/10 MAC OS, NetWare, UNIX ou Linux |
DADOS DE TESTE | |
---|---|
Potência de Transmissão WiFi | CE EIRP: <20dBm(2.4GHz) <23dBm(5GHz) FCC: <30dBm(2.4GHz & 5GHz) |
Sensibilidade de Recepção WiFi | 5GHz: 11a 6Mbps:-93dBm;11a 54Mbps:-78dBm; 11ac HT20 mcs8:69dBm;11ac HT40 mcs9:-65dBm; 11ac HT80 mcs9:-62dBm; 2.4GHz: 11g 54Mbps:-78dBm; 11n HT20 mcs7:-74dBm; 11n HT40 mcs7:-71dbm; |
